Radar provides the level monitoring solution within a UK paper mill

Radar sensor from UWT is the bespoke solution for content measurement Continuous level monitoring devices regulate and control liquid or solid levels in a processing plant, helping to streamline the operation, eliminate human error and thus maximise overall efficiency. And so level control devices should be and are an investment that needs careful research and consideration to ensure that the investment in such kit is wisely made. Our customer, a large paper mill based in the UK, approached UWT UK Ltd to achieve all the above for the monitoring of their coal silo and in a backwater tank. A mechanical system in the coal silo and ultrasonic technology in the backwater tank had both failed leaving the monitoring task being executed manually using a tape measure dropped in through the tops of the silo and tank. Clearly, it was time to upgrade. So the customer approached UWT UK Ltd to visit and inspect the applications and to advise on a long term, reliable solution within budget. Time & consideration During the site visit the UWT

20.03.2024 | 375x | Product description | |

Rotary Paddle Level Switch for overfill and dry run protection

The terms ‘functional safety’ and ‘safety integrity level (SIL)’ have occurred more frequently since the publication of the international standard IEC 61508/IEC61511. SIL2 for rotating paddle series Particularly in systems with hazard-causing processes, such as in chemical plants, the consideration of functional safety has become indispensable. On this basis safety-related practices, design principles and error considerations must be met in order to minimize the risk of a dangerous failure. Risk mitigation in accordance with SIL2 The UWT engineers focused on this topic and designed the rotating paddle switch Rotonivo® RN 6000 series according to the normative requirements of functional safety to ensure safety functions in a risk mitigation in accordance with SIL2. Typical safety functions are overfill and dry run protection. Full, demand or empty Depending on the requirements, the Rotonivo® rotary paddle switch is used as a full, demand or empty detector in storage silos or process vessels and is suitable for use in almost all solids. With its simple electromechanical measuring principle it can also be adapted for extreme

12.03.2024 | 341x | Product description | |

No loss of hops and malt with the right measuring technology

Active batch balancing & food conformity & CIP suitability In the food industry, absolute hygiene is of crucial importance, with high demands being placed on the measurement technology to be installed in terms of design, functionality and reliability. In the beverage industry in particular, these requirements can be very specific. A Peruvian beer manufacturer was looking for suitable solutions for overfill and running-empty protection for its process tanks with different solid and liquid raw materials. The malt dosing system was designed with innovative RF technology. Capacitive limit switches from UWT were installed, which are designed for high temperatures and applications with highly caking materials such as the viscous liquid of the malt mixture. It tastes better when you know your limits The difficulty in beer production lies in controlling the correct malt dosage during the addition of water for dissolving. This was due to the fact that the grain became very sticky after moistening, which led to false alarms for

11.01.2024 | 601x | Product description | |

NivoTec®- Level monitoring and visualization system

Choose your suitable system for level monitoring & visualization from the UWT NivoTec® product portfolio Various technologies are available for level indication. Simple LED digital displays for the evaluation of a 4-20 mA signal for installation in control cabinets or up to wall mounted touch panels and web server modules with visualization software. These can then be configured on a project by project basis and adapted to customer requirements. UWT has standardized product versions of the NivoTec® NT 4000 series, which meet many requirements of a level indicator and monitoring at a cost effective price. The NT 2000 series includes control cabinet modules with local display and control elements, which is useful for a limited number of containers. The NivoTec® NT 3000 series can be individually adapted to the customer’s project. This web server solution meets all requirements of modern silo level monitoring.

06.12.2023 | 507x | Product description | |

Continuous & point level measurement with guaranteed Quality

High-quality measurement technology with exclusive 6-year warranty; The UWT quality promise: Modern - Durable - Sustainable The UWT Group is considered an expert for simple, safe and accurate level measurement, point level determination and interface detection in any type of bulk solids and liquids. The many years of success are based on the high quality of the products, innovative thinking and close cooperation with customers. That is why the company is the first manufacturer of measurement technology on the global industrial markets to offer a warranty extension to 6 years for all UWT sensors. The UWT quality promise Modern - Durable - Sustainable; Plant builders and end customers around the world appreciate the customer-specific and user-friendly technologies of the German medium-sized company as well as the easy handling and longevity of the UWT sensors. With many years of experience, the company knows that high-quality and maintenance-free sensor technology is an important aspect for plant operators in all industries. Measurement technology at the highest level Guaranteed quality

30.11.2023 | 421x | Press release | |

Upgrade of level monitoring system in grain storage

A large grain storage facility in the south of England required a reliable content measuring device to replace an old acoustic wave system which was no longer functioning. Configured was a non-contact radar measurement device from UWT combined with a visualization software. Non-contact continuous level measurement UWT (UK) Limited proposed the use of the free-radiating radar NivoRadar® NR 3100 which could be supplied with an aiming flange. The integrated aiming flange allowed the radar to be mounted in the same position as the previous acoustic wave device which was close to the silo side wall and which allowed for the narrow 4˚ beam to be aimed towards the lowest point of the silo. This saved the customer time and money as they didn’t need to move the mounting position towards the centre of the silo where the silo was filled from. Free-radiating radar sensors can determine the level of a medium without contact. The so-called FMCW radar measurement method (Frequency Modulated Continous Wave) is used for this purpose. The transmitted signal is modulated between two known frequency values (NivoRadar® 78...79 GHz) and the difference

22.11.2023 | 508x | Product description | |

Level control in pressure conveying containers for seaweed meal

An animal feed manufacturer in Ireland was looking for reliable level indicators including overfill protection and empty protection as part of the modernization of the plant equipment. When installing the sensors in different pressure conveying containers for seaweed meal, the high dust intensity had to be considered in particular. By planning a capacitive level switch from UWT with innovative RF technology, a compatible solution that is robust and delivers reliable results was found. It is also advantageous for this application if the sensors have small connection threads and can implement precise switching with a quick response. Excursus: Seaweed meal in animal feed Since 1994, feeding animal meal to pets and farm animals has been banned throughout the EU because it is a potential transmitter of the BSE pathogen. That’s why seaweed flour is now used as an alternative. Seaweed meal is added to the feed of pets such as dogs or farm animals such as cattle as a dietary supplement. It is rich in various nutrients, vitamins, fiber, proteins, omega-3 fatty acids and minerals such as iodine, potassium or sodium. All of these nutrients have positive

08.11.2023 | 1258x | Product news | |

Review to a successfull Exhibition at Powtech 2023

TECHNOLOGY. PERFORMANCE. PARTNERSHIP. Experience level measurement technology Welcome at UWT, Great team from UWT, UWT Export Team - new look, The hot wire by UWT - lot of fun, Gaming time - fun time, Nice visitor - great honor, More visitors are interested, Thanks a lot to all our visitors, Bavarian cheese was presented by UWT Ladies, Kevin Walter presents the coloured solids, Colleagues for a visit

02.11.2023 | 370x | Photo reportage |

SIL2 for rotating paddle series Rotonivo® from UWT

Rotary Paddle Level Switch for overfill and dry run protection with SIL2 certification The terms ‘functional safety’ and ‘safety integrity level (SIL)’ have occurred more frequently since the publication of the international standard IEC 61508/IEC61511. Particularly in systems with hazard-causing processes, such as in chemical plants, the consideration of functional safety has become indispensable. On this basis safety-related practices, design principles and error considerations must be met in order to minimize the risk of a dangerous failure. The UWT engineers focused on this topic and designed the rotating paddle switch Rotonivo® RN 6000 series according to the normative requirements of functional safety to ensure safety functions in a risk mitigation in accordance with SIL2. Typical safety functions are overfill and dry run protection. Depending on the requirements, the Rotonivo® rotary paddle switch is used as a full, demand or empty detector in storage silos or process vessels and is suitable for use in almost all solids. With its

07.09.2023 | 476x | Product news | |

Radar measurement in fine sand of building materials production

A German building materials manufacturer was looking for compatible level sensors in its narrow, high storage silos for very fine sand, among other things. A non-contact measurement with free-radiating radar measurement technology from UWT was preferred. The advantages of non-contact radar level measurement lie in its ability to provide accurate measurement regardless of the properties of the medium (e.g., density, dielectric constant). It also works in adverse environments with high temperatures, pressures, vibrations or dust. The NR 4100 has been installed in several storage silos for level measurement of very fine sand (0-1 mm). The high frequency 80 GHz radar sensor of the NivoRadar® series offers a high resolution as well as a robust design. - Max. adjustment: 1,000 m - Min. alignment: 15,000 m The echo profile looked top notch. Installation and commissioning were quick and straightforward. Pairing the devices via Bluetooth with the UWT LevelApp worked intuitively and ensures transparent and modern level monitoring. Special features of the application/application data: - Low DK value of the sand -

23.08.2023 | 543x | Product description | |

Robust level measurement you can build on

One of Italy’s largest building industry suppliers equipped its storing processes with suitable level measurement technology. The challenge was to find a system which can measure reliably even in this extremely dusty environment. Together with UWT a free-radiating continuous level measurement was configured. - Smart non-contact continuous radar determination Due to the fast development of the building and quarry industry in many European countries during the past years, the demand for more solution approaches for applications of cement plants has increased. Solutions of appropriate sensor technology for content and point level measurement have to be found in order to support the process flow of the cement production in the most reliable way. A manufacturer of concrete and plaster products for the building industry in Italy wanted to modernize his process flow with a redesign of the measuring equipment. Pre-dosed products are mainly offered, which are supposed to make life on the construction site easier. The manufacturer was amongst others looking for a reliable level measurement

19.07.2023 | 575x | Product description | |

A matter of heart - Severn Hospice

As part of our UWT cares commitment, our colleagues at the UWT UK subsidiary in Shrewsbury drew our attention to the Severn Hospice, which provides free specialist care and support to families living with an incurable illness. Since 1989, Severn Hospice has provided free care and support to more than 34,000 people and their families in times of dire need. All the care provided to thousands of people each year is only possible thanks to the generous support of communities and donations. Severn Hospice is a very high-profile charity dedicated to offer patients and their families with specialist medical care, emotional support and chaplaincy service. Behind each family that is helped stands a large, caring team and hundreds of friendly supporters who make that all possible. With our donation of £1,800 (€2,070) we want to support this great work of Severn Hospice. ” Our vision is a world where people are cared for at the end of their life as well as they were at its beginning.”

04.07.2023 | 526x | Press release |

Contact-free radar solution for water treatment slurry

Continuous level measurement technology from UWT was installed for the upgrade of the wastewater system of a company in the food manufacturing industry in Colombia. Together with the local partner INTAI INGENIERIA S.A.S. several on-site tests were carried out and a non-contact solution was preferred. Chemical and disinfectant substances require chemical resistance and a robust design. Accurate and fast level measurement The manufacturer of various dairy products needed a reliable solution to control medium solid waste from the plant’s effluent treatment process. The concrete tanks are 4 meters long and the material has the consistency of sludge with a DK value of 4. The pressure is in the range of 0.8 bar (11.6 psi) up to 5 bar (73 psi). There is no electrostatic charge. The process temperatures reach up to 80 °C (176 °F). Within the process hoppers there is a high degree of moisture and some build up. Accuracy as well as a quick response time were especially relevant to the process. High frequency signal Finally, the NivoRadar® 7100 was implemented into the wastewater treatment system. The certified sensors were

13.06.2023 | 693x | Product news | |

Let´s start the new chapter of the UWT brand

TECHNOLOGY. PERFORMANCE. PARTNERSHIP. The UWT Family and presented its new brand story at its ”7th International Sales Meeting 2023”, showing that we are ready for more worldwide New CI launched by UWT, Uwe Niekrawietz with Sumit Mujamder (UWT-India), UWT Export Team - new look, UWT Ladies at the bavarian evening, Alfons Kennerknecht - our party guarantee, Culinary delights are never missed, UWT invites the world, UWT reaches out, Team UWT National , NEW product overview, UWT Trainees, Organisation needs to be rewarded, , We proudly present the Team Export Area Sales Manager, Team UWT Mexico meets - KDK Argentina,

07.06.2023 | 599x | Photo reportage |

Capacitive RFnivo® 3000 is the first choice for many bulk applications

Innovative all-rounder for measuring all types of bulk materials that combines all important features of a reliable measurement technology and is additionally very user-friendly The significance of the gear mechanism is not to be underestimated. Many a “simple” type of component can soon become a problem if it’s not working reliably. In situations where level monitoring is required, costly events such as over filling of the silo can be avoided. Sensors have to be designed with a high degree of compatibility for processes, so that they can be seamlessly integrated into installations ensuring the optimal solution. All-rounder single rod probe We are often asked whether there is one measurement principle, which works reliably in all bulk solids applications? Is there one sensor that can cope with low bulk density, bridging, caking, abrasiveness, corrosion, high tension and leverage forces, high and low process temperatures and pressures, low and fluctuating dielectric value as well as being able to offer a short reaction time? To date, the answer to this question has been “no”, there has not been any one measuring principle to solve

10.05.2023 | 691x | Product description | |

Behind the scenes at UWT

There is always something going on. Here you can get to know the UWT family better. What makes UWT an employer? What is our source of motivated and satisfied employees? Here you can get to know the UWT family better. By the way: There are many opportunities to contribute to the success of UWT, in a permanent position, apprenticeship or study, information on how to become part of our team can be found in the career section.

30.03.2023 | 649x | Press release | |

Capacitive level measurement technology for detection of crude oil

For the implementation of a reliable level limit measurement within lubricating oil pipelines of tyre production, the limited space situation as well as high material viscosity had to be considered in particular. Level limit measurement in pipelines with lubricating oil One of the largest global tyre manufacturers needed a reliable point level sensor to measure the level in a 3” tube with lubricating oil in their subsidiary in Argentina. Due to the viscosity of the material, not every measuring principle works in this installation situation. The crude oil has a DK value between 2 and 3, the process pressure can be up to 0.8 bar (11.6 psi) and the process temperature up to 80 °C (176 °F). In addition, there is a high moisture content with condensate within the atmosphere. In this case, the ideal solution was UWT’s Capanivo® CN 7000 capacitive point level sensor. The sensor has a ½” stainless steel thread and a PPS probe. The integrated active build-up compensation prevents incorrect switching due to material adhesion around the probe. Its reduced installation length ensured optimal implementation within the 3” pipe. Together with the local partner KDK - CIA ARGENTINA

28.03.2023 | 736x | Product description | |

Level measurement with enhanced process safety and quality

Level measurement technology with maximum quality: Rotary paddle switch devices equipped with metal detectable shaft sealing ring for a higher degree of security Rotary paddle switches are often used in the food sector to monitor material flows, for example in conveyor technology or in dosing and filling systems. They are used to indicate full, required and empty bulk goods such as grain, flour, sugar, spices and other foods. For hygienic reasons, the built-in devices are often made of stainless steel or other easy-to-clean materials. They have to meet the high requirements of the food industry, which often has very strict regulations and standards for food hygiene and safety. A metal detectable shaft sealing ring is a special seal ring made from materials that can be detected by metal detectors. Such shaft seals are often used in the food and beverage industry to ensure that no unintentional foreign objects can enter the product. Metal detectable shaft seals The high requirements of the food industry met with metal detectable shaft seals. In addition to the four existing shaft sealing rings, the metal-detectable option

27.03.2023 | 610x | Product news | |

Precise interface measurement of different solids in liquids

Project planning options for interface detection with electromechanical lot system NivoBob® for continuous level measurement or vibrating fork Vibranivo® for point level detection from UWT GmbH. There are several industries where sludge levels or solids in liquids need to be measured. For example, in sediment containers or basins, filters or lamella separators in the metal industry, chemical plants, lime or gravel works and the waste water industry. The measuring accuracy and durability of the sensor technology is important. Dirt, chemicals and gases often affect the sensors and require special resistance. The NivoBob® series NB 3300/3400 meet the requirements of many interface measurements and are very reliable due to the simple measuring principle. For level evaluation an analogue signal 4-20mA and a Modbus RTU/Profibus DP interface are available. Vibrating forks of the Vibranivo® series VN 1000 or VN 5000 can be used to measure the point level of sludge and solids in liquids. The parts in contact with the medium are made of resistant stainless steel. With the versions VN 1030 and VN 5030 even depths of approx. 4 m (13,12 feet) are realizable when installed

08.03.2023 | 820x | Product description | |

Warranty extension up to 6 years for all our sensors

Continuous, Point level & Interface level Measurement with Guaranteed Quality The UWT Group is considered an expert for simple, safe and precise content level measurement detection, point level determination and interface detection in all types of bulk solids and liquids. The many years of success are based on the high quality of our products, innovative thinking and close cooperation with customers. That is why we are the first manufacturer of measurement technology within the global industrial markets to offer a warranty extension up to 6 years for all our sensors. Modern - Durable - Sustainable Plant operators and end customers around the globe appreciate our customer-specific and user-friendly technologies as well as the easy handling and durability of the UWT sensors. ★ Many years of know-how ★ User-friendly technologies ★ Maintenance-free sensors Guaranteed Quality for more Planning Security The maintenance-free measurement technology meets the highest safety standards and is internationally certified. With a

31.01.2023 | 722x | Press release | |

Continuous level measurement of acetone with melted rosemary

To produce natural rosemary extract in Slovenia a continuous content measurement for several tanks was installed. These work with the capacitive measuring principle, which is becoming increasingly popular, and have been configured for special process connections. Compensation for the materials caking to the sensor was crucial for the reliable determination of rosemary acetone. - Capacitive sensors for the Ex area - ATEX Zone 0 A producer of natural rosemary extracts was looking for a reliable solution for continuous level measurement in five stationary tanks of different volumes. The measuring range is up to 2.2 meters (72.18 ft). There is condensate in the atmosphere. All tanks are located inside the production building with process temperatures up to 80°C (176°F). The medium to be measured in the tanks is acetone with a 3% share of melted rosemary. Together with UWT Partner Sensor d.o.o. after some on-site tests, the capacitive level sensor NivoCapa® 8000 was implemented for the content notification. The distinctiveness of melted rosemary is that it hardens at a certain

12.01.2023 | 759x | Product news | |

Capacitance empty detection in sulfuric acid

Level indicators working with the capacitive measurement principle can be used in all types and shapes of tanks, regardless of whether these are metallic or non-metallic. - PPS probe with 1-inch process connection - Chemical resistance & compact design Due to their high sensitivity, their compactness and the range of probes, they are suitable for a wide variety of industrial process requirements. A well-known manufacturer of aluminum sulfate in Peru was looking for a compact level measurement for its raw material tanks with 98% sulfuric acid. Due to the strong corrosion caused by the acidic material, the decision was made to implement the robust capacity indicator Capanivo® CN 7000 from UWT GmbH. Sulfuric acid is extracted from sulfur in a number of ways and is one of the most dangerous acids known in the world. The colorless and odorless chemical is viscous, water-soluble, hygroscopic and hardly corrosive. Due to its properties, sulfuric acid is used in a large number of different industries and is one of the most widely produced chemical raw materials in the world. Different sulfates are produced by reacting appropriate salts with

19.12.2022 | 883x | Product news | |

Annual Group Meeting at UWT

A long tradition at the Allgäu-region. The leaders of the subsidiaries around the world meet each other. , , , , , , , , , , , , , ,

24.11.2022 | 801x | Photo reportage |

UWT GmbH expands in Switzerland

This project aims to significantly increase the presence of UWT equipment in Switzerland. We are looking for distribution partners. For the expansion and systematic development of the market in Switzerland, we are looking for distribution partners on the one hand and plant manufacturers and large end customers on the other. * Business partner brokerage This project aims to significantly increase the presence of UWT equipment in Switzerland and to establish a long-term partnership with a Swiss company. This project was funded by the European Regional Development Fund. This Fund aims to strengthen economic, social and territorial cohesion in the European Union.

22.11.2022 | 794x | Press release | |

UWT solution in cooling water with H2 gas

Compact device NivoCapa® for precise level measurement for a wide range of applications; used in different liquids, pastes, foams and slurries and can be implemented in all types and shapes of tanks. Capacitance level measurement in tanks Level sensors that work according to the capacitive measuring principle are used in different liquids, pastes, foams and slurries and can be implemented in all types and shapes of tanks, metallic or non-metallic. They have a very high level of precision in both conductive and non-conductive media. If you look at the whole thing in practice, it becomes clear how versatile the capacitive measuring principle is in very different process conditions. Proven technology For a steel-producing plant, a continuous level measurement, which works unaffected by steam or pressure fluctuations within a very small measuring range, was implemented with the NivoCapa® NC 8000 in water for gas cooling. The proven technology with active buildup compensation and a tunable oscillator was a flexible solution for optimizing the manufacturing process. Measurement accuracy One of the top 10 steel producers worldwide was looking for an insensitive

25.10.2022 | 908x | Product description | |

Measurement technology for level and employee health at UWT

We not only measure the level, but also the health of our employees. Measurements with Dr. Pedro Gonzalez On Monday and Tuesday, October 10 and 11, 2022, the UWT annual focus days for health took place again. These started with a lecture on the topic of stress, i.e. its causes and consequences. On the programme this year were measurements with Dr. Pedro Gonzalez: Cardioscan, Bodyscan, and metabolism measurement, whereby a breathing gas analysis is carried out in a few minutes. Cardioscan * ECG * Stress value * Training plan with pulse values Bodyscan * Muscles * Water * Fat Metabolism measurement * How many carbohydrate and how many fat calories does the body need as a basal metabolic rate per day? * How active is the cell metabolism? * How is fat burning optimised? At noon, all UWT members had a healthy lunch.

17.10.2022 | 794x | Press release | |

Trade fair impressions of Powtech 2022 from UWT

Once again, a successful fair has come to an end. Beautiful impressions - Thanks to all visitors - Thanks to our fair team Invitation to Powtech 2022, You are warmly welcomed by a great team, Already present on the way to the fair, Many interested visitors at our booth, Liquids Line in Focus, Introducing our new NivoRadar® 7200, UWT Level App, Andrea Fisher at the Fair Game - Always the Hammer, , Our products at a glance, Interesting conversations under the radar

07.10.2022 | 796x | Photo reportage |

Expert Talk on contact free radar sensors NivoRadar 4000/7000

Guoyan Zhang-Mailänder and Nikolas Oppenberger present an Expert Talk on contact free radar sensors NivoRadar® 4000/7000, controllable via UWT Level App Compact radar sensor for solids & liquids applications: - Cost effective radar solution - 80 GHz technology - No blocking distance - High sensitivity (DK value ≥ 1.1) - Temperature solution -40 to +80°C Your benefit: - Reliable and high-precision measurement results independent of medium properties and ambient conditions for trouble-free operation - Inexpensive and at the same time durable, robust and maintenance-free measurement technology - Simple and user-friendly configuration, commissioning and diagnosis of the radar level sensor via the UWT LevelApp, optional Plug on Display

27.09.2022 | 1098x | Product news | |

We invite you to visit us at the POWTECH 2022

In Hall 4a, Booth 117 you can discover our new Sensors Experience what is possible with the right measurement technology Innovative level measurement devices presented live at Nuremberg from September 27 - 29th, 2022 News from the world of radar. We have a lot of technical innovations in our luggage In addition to our guided wave radar sensors we have expanded our portfolio of free-radiating/non-contact sensors. We will present our new free-radiating FMCW radar sensors for determining the level of bulk goods and liquids at the POWTECH live and in action. The new non-contact radar series for continuous level measurement has been equipped with the high-frequency 80 GHz FMCW technology and a very narrow beam angle. The internationally certified radar sensors detect with high measurement accuracy and short reaction times, without blocking distances in the upper part. A wide range of mounting accessories and flexible temperature solutions enable the compact measurement technology to be used in many industrial

19.09.2022 | 864x | Press release | |

We invite you to visit us at the Achema 2022 in Frankfurt

In hall 11.1 booth 73 a, we`ll enjoy your visit with a refreshment Get your free entry ticket here, with your voucher code: A_Dfs#mvR9 Come and be part of our productlaunch of the new series NivoRadar® 4000 and 7000. UWT supply Point level measurement and Continuous level measurement sensors for bulk solids and liquids applications. Different measurement techniques are used depending on the medium and application in question. A destinction is made between Point level detection, Continuous level measurement and Interface Detection.

09.08.2022 | 862x | Press release | |

Level measurement and monitoring in plastic raw materials

Modern solutions for efficient storage processes Measurement technology Rotonivo® and NivoBob® combined with data visualisation NivoTec® Modern, high-quality technologies ensure a continuous stress-free manufacturing process in plants. When it comes to detecting fill levels in silos and material processing operations, sensors with a high level of compatibility for different process containers provide the optimum support for a smooth process. Depending on the processing stage, the material to be controlled can be of very different nature and place different demands on the measurement technology to be used. Users from different industries with a number of scattered storage silos consider it increasingly necessary for their plants to be equipped with automated visualisation and monitoring of the data in addition to continuous measurement of the fill levels. In order to guarantee a professional solution in terms of precision and process reliability for content measurement during the various stations in the manufacturing process to support a production facility, it is necessary to react to the respective

04.08.2022 | 1018x | Product description | |

Solutions by UWT for level control of cement in Italy

One of Italy’s largest building industry suppliers equipped its storing processes with suitable level measurement technology. Robust level measurement you can build on. The challenge was to find a system which can measure reliably even in this extremely dusty environment. Together with UWT a free-radiating continuous level measurement was configured. In addition to that a vibrating fork was installed for overfill protection within the truck transporters. - Smart non-contact continuous radar determination Due to the fast development of the building and quarry industry in many European countries during the past years, the demand for more solution approaches for applications of cement plants has increased. Solutions of appropriate sensor technology for content and point level measurement have to be found in order to support the process flow of the cement production in the most reliable way. A manufacturer of concrete and plaster products for the building industry in Italy wanted to modernize his process flow with a redesign of the measuring equipment. Pre-dosed products are mainly offered,

02.06.2022 | 1305x | Product description | |

Robust UWT measurement sensors- you can BUILD on

Solutions for the cement & building industry made by UWT We take a closer look at typical cement processing issues during the preparation of the raw mixture as well as the production of clinker. Our Product Manager N. Oppenberger has been looking into the very demanding requirements placed on measurement technology in the building and power industry. Together with G. Zhang-Mailänder, Area Sales Manager Asia Pacific he explain solutions for overfill protection, empty notification as well as continuous level measurement for the different processes and sub-processes.. In this session you receive an insight into how made-to-measure level measurement instruments ensure the smooth running of cement production facilities worldwide. Our experts will also demonstrate where certain technologies work and where they don’t, as well as investigating particularly challenging applications giving specific recommendations what sensor technology is best suited to solve them. ⚐ Precise and robust continuous and point level measurement

05.05.2022 | 1112x | Product news | |

TDR solution in ethanol

Safe level measurement in ethanol tanks with guided wave radar For the storage processes of ethanol of a Swedish producer the guided wave radar for continuous level determination was implemented within several tanks. TDR sensors are easy to put into operation and deliver reliable measurement results even under extreme process conditions. Since the functional principle does not require any mechanically moving parts, a maintenance-free manufacturing process is ensured and system availability is increased. In addition, TDR sensors meet the highest safety standards, which makes them the technology of choice especially in the oil, gas and chemical sectors. With these capabilities, TDR sensors make a noticeable contribution to increasing the productivity of the plant. Robust sensor design that can be used in a variety of ways Radar technology has gained more and more importance over the past decades and has been continuously developed. The area of application now extends from simple installations to complex process vessels with a

25.04.2022 | 1676x | Product description | |

UWT opens office in Mexico

In the 45th year of existence of UWT GmbH, the 7th international sales office is now founded in Mexico. With its own branch office UWT Level Control de S. de RL de C.V. in Santiago de Querétaro, Country Manager José Cruz is introduced. Opening UWT Mexico, UWT Office Building Santiago de Querétaro, Fernando Soares Pinto welcomes the team, Fernando Soares Pinto shoes the products, Uwe Niekrawietz welcomes Jose Cruz as the leader of UWT Mexico, Ladies support at UWT Mexico, Great teamspirit at the UWT Mexico team, Colleagues from Mexico find out how reliable the UWT Sensors are, Uwe Niekrawietz is introducing the UWT Famliy

17.03.2022 | 998x | Photo reportage |

POWER UP with smart Level Measurement Solutions

One of India’s largest energy suppliers equipped its coal handling processes with suitable level measurement technology to optimize the whole power plant flow. How to equip the lifeline of the power plant In addition to natural gas, oil and nuclear power, coal is a major factor in the generation of electrical power. In line with the rapid development of the economy and of technology we have a continuously growing demand for electricity as mankind invents computers, intelligent home appliances, electric cars, intelligent robots and many more products that use electricity. Still rising consumption e.g. in China, India and the United States could bring global coal-fired power demand to a new all-time high. The requirements for electric power equipment are increasing: the need for them to be safe and reliable, with high availability, easy to install, no leakage, maintenance-free and to meet the requirements for environmental protection. End of last year a big coal-fired power plant, located in Kharagpur, West Bengal, was looking for uncomplicated, high-performing and absolutely reliable measurement technology at an affordable

23.02.2022 | 1370x | Product description | |

Upgrade of level monitoring system in grain storage

A large grain storage facility in the south of England required a reliable content measuring device to replace an old acoustic wave system which was no longer functioning. Non-contact continuous level measurement UWT (UK) Limited proposed the use of the free-radiating radar NivoRadar® NR 3100 which could be supplied with an aiming flange. The integrated aiming flange allowed the radar to be mounted in the same position as the previous acoustic wave device which was close to the silo side wall and which allowed for the narrow 4˚ beam to be aimed towards the lowest point of the silo. This saved the customer time and money as they didn’t need to move the mounting position towards the centre of the silo where the silo was filled from. Bring the levels to where the planner needs them The visualising system that the customer had been using previously was very basic and limited and did not allow them to display the contents in any other way than the level of the material. The customer required the contents of the silo to be displayed in tonnes or percentage of fill. The NivoTec® NT 4600 with cabinet mounted digital display fulfilled

10.02.2022 | 1358x | Product description | |

Solutions for the sugar industry - Webinar on Demand

Sugar beet - as versatile as UWT level measurement devices Our Product Manager N. Oppenberger has been looking into the specific requirements for measurement technology in hygiene-sensitive processes in the food production. He discovered that the requirements vary very much depending if you are looking at it at a national or an international level. Bearing this in mind he explains what should be considered when choosing measurement technology. In this seminar a focus is put on the field of sugar processing which cover solutions for overfill protection and empty notification of bulk goods and liquid media. In this live session J. Bareth, Area Sales Manager Central Europe and N. Oppenberger, Product Manager give you an insight into the different level measurement devices used in sugar plants around the world. They also demonstrate where certain technologies work and where they don’t. Our experts will be investigating particularly challenging applications giving specific recommendations what sensor technology is best suited

23.12.2021 | 1674x | Product description | |

Establishment of a subsidiary in Brazil with unexpected challenges

s UWT sets up a new office in Brazil, the company is keen to be part of and support the local community. We have become aware of a center for seriously ill children who have suffered particular hardship during the recent challenging times. Enabling optimism When @uwtbrasil set up its branch, the Boldrini Children’s Centre, 7 km from our office in Campinas, became a matter of the heart. The @centro_infantil_boldrini is a humanitarian hospital and treats children and young adults with cancer and blood diseases. 3 euros were collected per rapid antigen test in Betzigau and so far 2,000 euros have gone to the Centro Boldrini. The whole story and more information about the great work of Centro Boldrini - follow this Link

20.12.2021 | 1316x | Press release | |

Webinar on demand - Solutions for the chemical industry

In our autumn special it’s all about reliable solutions for overfill protection, empty notification as well as continuous level measurement of bulk goods and liquid media of the chemical sector. Together with Area Sales Manager Sub-Saharan Africa/France, Dr.-Eng. Valéry T. Kemtchou, Product Manager N. Oppenberger has been looking into the very specific requirements for measurement technology within the chemical industry. They explain where certain technologies work and where they don’t. What is the main focus of this webinar? Level measurement devices installed within applications in the chemical industry are exposed to aggressive, adhesive, abrasive and corrosive media. Also the requirements can demand that very light bulk goods are to be detected and measured accurately. In this live special you receive an insight into choosing the right measurement technology in conjunction with the aspect of process safety within chemical plants. Our experts demonstrate particularly challenging applications giving specific recommendations of what sensor technology is best suited to solve them.

15.12.2021 | 1389x | Press release | |

Silo management with NivoTec® for grain mills and their customers

Bakeries, the customers of the mills, often place their orders to late and the mills are faced with having to supply material immediately in order to avoid production stop at the bakeries. In Germany alone there are more than 260 large flour mills, in Asia the grain market is significantly greater and a very important industry. All around the world the situation is similar: Well-planned routes and carefully calculated stock levels are vital to achieve max. cost optimization during the material delivery process, however these are more than often jeopardized by daily reality. This leads to unnecessary logistics costs caused by multiple deliveries and ultimately to an increase in costs for sides, the supplier and the customer. This is obviously in no one’s interest. But why are we confronted with these “fire-fighting” situations and how can they be avoided? Lack of storage management in bakeries Even bakeries with multiple storage silos often do not have an automated level monitoring system to control their inventory levels. Therefore these stocks have to be checked manually on a regular basis and an order has to be triggered to the flour supplier

02.12.2021 | 1577x | Product description | |

NivoGuide® NG 3000 by UWT as Solution in Cement application

Guided wave radar in narrow storage silo for overfill protection and empty indication. Robust and reliable for a continuous, stress-free production process. Robust and totally reliable In aggregate, quarry and mining applications level measurement devices need to be robust with total reliability as standard to ensure a continuous stress-free production process. Modern level measurement For a concrete and cement manufacturer in Germany who has implemented guided wave radar sensors this level measurement technology offered multiple support for his storage process optimization. The TDRs with their high compatibility are used for consistently accurate continuous level detection under difficult varying process conditions, such as high pull-off forces, caking or condensate formation. Unaffected by dust and build-up The stored raw products and additives undergo different processing stages on the way to the final mortar and different kinds of concrete, ready-mixed concrete and special concretes. The solids in particular have different densities, particle sizes with different dust development and a differing moisture content.

04.11.2021 | 1473x | Product description | |

Smart Capanivo® 7000; Capacitance measurement reinvented

Capacitance measurement technology at its new level. Say hello to our new Capacitance Level Switch You Asked, We Listened New features - more models - IO-Link technology The capacitive level limit switches are used as a full, demand or empty detector as well as for interface measurement (for example, oil / water or foam / liquid). It can also be used for leckage detection in double walled vessels, tanks and silos or in moldings and collecting ponds. The Capanivo® 7000 sensor is suitable for installations in all kinds of liquids, pastes, foam and slurry. The newly redesigned series now benefits from a new look, amazing new features, a range of new models and latest IO-Link technology on board. Very compact capacitive level detection for flexible use in a variety of applications The electrodes in the sensor form a capacitor. If the product comes into contact with the sensor, the capacitance changes and the electronics converts it into a switching signal. The integrated “Tip Sensitivity” and “Active Shield” technology guarantee a high level of functional reliability

30.09.2021 | 1689x | Product news | |

Time to POWER UP with smart Level Measurement Solutions

With the rapid development of the economy and technology, the demand for electricity is constantly increasing. Watch our Webinar on Demand anytime - in English Our Product Manager N. Oppenberger has been looking into the very specific requirements for measurement technology within the power industry. Together with J. Bareth, Area Sales Manager Central Europe, he explains solutions for overfill protection, empty notification as well as continuous level measurement of bulk goods and liquid media required for the different production processes. *What is the main focus of this webinar? In line with the rapid development of the economy and of technology we have a continuously growing demand for electricity as mankind invents computers, intelligent home appliances, electric cars, intelligent robots and many more products that use electricity. To produce the power required many challenges have to be overcome, some of which we would like to cover in our webinar. In this live special you receive an insight into choosing the right level measurement sensors for the different processes and sub-processes of the power sector. Our

22.09.2021 | 1414x | Product description | |

Resistant RF level limit switch with dust-proof design by UWT

Capacitance measurement technology RFnivo® 3000 for conveying process optimization for a silicon metal manufacturer A silicon metal production facility in Iceland was looking for a suitable level measurement technology to coordinate the filling of sea containers with silicate rock. Due to the very abrasive material, a heavy-duty capacitive probe should be used. With the project planning of a proven point level switch from UWT with the innovative RF technology, a compatible solution, which is robust and delivers reliable results, could be found. Silicon metal is used in a variety of applications in the chemical industry, e.g. in the manufacture of siloxane and silicones, as well as in the production of high-strength aluminum alloys for the automotive industry. It is also often a primary raw material in the manufacture of photovoltaic modules. In the production processes of a manufacturer in Iceland, an above-average sustainability balance is strived for, which includes equipping its system with modern and efficient component technology. Therefore, the implementation of innovative

13.09.2021 | 1388x | Product description | |

UWT Radar Level measurement at the speed of light

Learn more about our radar level transmitters to reliably measure solid and liquid materials in silos and tanks. We have solutions for the most diverse industries. Our radar sensors include a non-contact series NivoRadar® 3000 and a guided wave radar serie NivoGuide®3000 for solis and NivoGuide® 8000 for liquids. Electromagnetic waves form the basis of level measurement with radar. A radar sensor emits a focussed electromagnetic wave that is reflected by objects as an echo and is then evaluated by the sensor. In addition to free-radiating radar sensors, the radar category also includes those based on guided microwave technology, which are referred to as guided radar, TDR (time domain reflectometry) or also GWR (guided wave radar) sensors. The fundamental difference between free-radiating and guided radar sensors is the way the electromagnetic waves reach the medium to be measured. While free-radiating radar sensors use special types of antennas to transmit the waves in the direction of the material without contact, guided radar sensors require a probe (rod or cable) as

23.08.2021 | 1901x | Press release | |

Webinar: radar level measurement in demanding situations in metallurgy

UWT Product Manager N. Oppenberger and Area Sales Manager A. Woloschin will be highlighting the best solutions for the very demanding requirements placed on measurement technology in the metal and metallurgy industry. Red-hot solutions that withstand more than the summer heat Save the date for Webinar in English language on August 05th, at 2 pm. What is the main focus of this webinar? In this live summer special you will receive an insight into choosing the right level measurement sensors for the different processes and sub-processes in metal production. Regardless, if you are looking for overfill protection, empty notification or continuous level measurement our experts will provide you with the answers. They will demonstrate where certain technologies work and where they don’t, as well as investigating particularly challenging applications giving specific recommendations what sensor technology is best suited to solve them. Webinar subjects * Robust and certified continuous and point level measurement under demanding process conditions such as: High dust content, High temperature, Aggressive material, High mechanical load, Different installation situations,

21.07.2021 | 1437x | Product news | |

Master Class - recording - TDR Guided Radar from UWT

Podcast on demand - allways available - Find out the benefits while using the NivoGuide® Series for continuous level controlin solids and liquids One for all. Standard or tricky? Solving difficult level measurement applications with guided wave radar The ultimate Guide: When things get a little tricky. TDR - Allrounder for Solids & Liquids: Looking for precise and safe continuous level measurement even when dealing with difficult process conditions such as: ~ dusty atmosphere ~ material with a low DK-value ~ very tall silos ~ particularly high loads on the probe ↪ Reliable and accurate, even when faced with difficult conditions such as extreme temperatures and pressures, steam, interface or build-up. UWT Product Manager Nikolas Oppenberger provides exciting tips & tricks concerning the TDR technology with useful examples of challenging applications and how the guided wave radar handles them. ↪ Special focus: Solutions with coaxial versions ↪ PLUS: Setup, configuration, commissioning & diagnostics - fast & easy ⚐ Are you faced with strong surface waves, fixings inside the tank

07.07.2021 | 1377x | Product description | |

Reliable level control from UWT in solids and liquids in malt plant

With the right measurement technology, hops & malt are never wasted - Active batch compensation & food conformity & CIP suitability In the food industry, absolute hygiene is among other things of upmost importance, whereby high demands are placed on the measuring technology to be installed in terms of design, functionality and reliability. Especially in the beverage industry, these demands can be very specific. A Peruvian beer producer was looking for suitable solutions for the overfill protection as well as the idling protection of its process vessels holding different solid and liquid raw materials required for the various production processes. To equip the malt addition process the innovative RF technology was chosen. UWT capacitive limit switches which have been designed to cope with high temperatures as well as applications with highly caking materials such as the viscous liquid of the malt mixture, were installed. * It tastes better when you know your limits In 11,000 B.C., agriculture and grain farming are born, and the history of beer begins. Archaeological findings report on beer consumption

09.06.2021 | 1698x | Product description | |

Mononivo® from UWT for process optimisation for hydropower plants

Solutions in the dam - Compact limit switch for process optimisation for hydropower plants as a backwater detector for wood chip conveyance One of the largest energy supply companies in the UK was looking for modern equipment for its northern dam with flexible metering technology. The electricity and natural gas supplier for local households and businesses has been focusing on hydropower generation for several years, in addition to wind power. The centrepiece of the dam’s hydropower plant is the installed wood chip system, which was recently implemented to curb pollution in the dam. Accumulated wood chips are transported to a designated storage area via a series of chain conveyors. These chain conveyors need to be monitored with modern and robust measurement technology. Namely, an indicator that functions as a full detector is required in the transfer chutes in order to detect a blockage with the wood chips in good time. Together with the subsidiary UWT (UK) Ltd in Shrewsbury, a safe solution was found after several tests with oscillating probes that work according to the vibration principle. The Mononivo®

19.05.2021 | 1617x | Product news | |

*

17.05.2021 | 1282x | Product description | |

IE expo China 2021-a strong trade fair performance in turbulent times

“We are delighted that, after a long wait, we were able to celebrate the first major event in Shanghai and that we have finally been able to exchange information personally again.” Markus Dicke, CEO of German Bio Energy Technology (Beijing) Co., Ltd. , , , , ,

27.04.2021 | 1188x | Photo reportage |

New e-commerce platform of UWT products

An enrichment for our prospective customers of the UWT Group The new platform brings great new features and will make finding and configuring a UWT product a breeze. Now we invite you to get to know our e-commerce platform in detail. How to rock our new e-commerce platform : - Quick way to the right product with product finder - Easy selection with product comparison tool - Quick and easy product configuration - Save, edit and share your configurations - Send configurations directly to the UWT sales team

06.04.2021 | 1966x | Press release | |

UWT solution for wood power plants with Rotonivo®

When detecting fill and limit levels, sensors with high compatibility for different process vessels offer optimal support for a smooth process. Level detection at high process temperatures for wood power plants When detecting fill and limit levels, sensors with high compatibility for different process vessels offer optimal support for a smooth process. The material to be checked can be of very different properties depending on the processing stage and make different demands on the measurement technology to be used. The rotation principle for point level detection in silos and material processing processes has proven itself for many decades. Even under extreme conditions. An energy technology company was looking for modern, high-quality technologies for point level measurement in order to optimally equip its wood-based electricity systems. The wood gas is converted into electricity after gas processing in a combined heat and power plant. ° When things get hot. Rotary paddle detectors when generating electricity using biogenic solid fuels Rotary paddle detectors are known for their easy-to-use functional

29.03.2021 | 2926x | Product description | |

International approval of UWT products

Whether ATEX, ISO 9001, or other important approvals. UWT can offer a lot What distinguishes UWT from others? - The reliability and the international certifications and approvals allow the customers and users of UWT products a safe use as level measuring instruments in different industries and applications. The various conditions and requirements are fulfilled by the approval certificates across the globe. Safe - Reliable – Certified

04.03.2021 | 2008x | Press release | |

Video - How to use the UWT products for level control

Solution for the food & beverage industry UWT supply level limit and continuous measurement sensors for bulk solids and liquids. Different measurement techniques are used depending on the medium and application in question. A distinction is made between continuous level measurement and point level detection. Furthermore, we offer complete systems for level monitoring and visualisation, working together with our customers to set up the installation and commissioning of our products. Customers around the world value us for our tailor-made solutions. Accordingly, we can manufacture complete system solutions to individual customer requirements. Our level sensors are characterised by their reliability, easy handling and long service life.

10.02.2021 | 1823x | Press release | |

Capacitance level measurement with NivoCapa® in tanks for gas cooling

Continuous level measurement in cooling water with H2 gas. There occur process-related low levels of vibration and steamin the atmosphere. Level sensors that work according to the capacitive measuring principle are used in different liquids, pastes, foams and slurries and can be implemented in all types and shapes of tanks, metallic or non-metallic. They have a very high level of precision in both conductive and non-conductive media. If you look at the whole thing in practice, it becomes clear how versatile the capacitive measuring principle is in very different process conditions. For a steel-producing plant, a continuous level measurement, which works unaffected by steam or pressure fluctuations within a very small measuring range, was implemented with the NivoCapa® NC 8000 in water for gas cooling. The proven technology with active buildup compensation and a tunable oscillator was a flexible solution for optimizing the manufacturing process. Measurement accuracy & corrosion-resistant design including PFA shielding. One of the top 10 steel producers worldwide was looking for an insensitive and

04.02.2021 | 2015x | Product description | |

Level measurement and monitoring in plastic raw materials

Measurement technology Rotonivo® and NivoBob® combined with data visualisation NivoTec® Modern, high-quality technologies ensure a continuous stress-free manufacturing process in plants. When it comes to detecting fill levels in silos and material processing operations, sensors with a high level of compatibility for different process containers provide the optimum support for a smooth process. Depending on the processing stage, the material to be controlled can be of very different nature and place different demands on the measurement technology to be used. Users from different industries with a number of scattered storage silos consider it increasingly necessary for their plants to be equipped with automated visualisation and monitoring of the data in addition to continuous measurement of the fill levels. Modern solutions for efficient storage processes In order to guarantee a professional solution in terms of precision and process reliability for content measurement during the various stations in the manufacturing process to support a production

18.01.2021 | 1936x | Product description | |

Capacitive RFnivo® probe with full coating protection

Point level detection with RFnivo® and the coating PPT with innovative corrosion protection In power plants, the demands made on the fill level sensors can be very high due to the fact that the sensors come into contact with aggressive media such as sulphur oxides, heavy metals or even acids. Where limit switches are used for dust detection in flue gas cleaning, they need to be robust enough in order to deliver reliable and consistent performance. Often maintenance costs or replacement of these sensors can be very high due to their quality not being adequate to meet the demands and so they achieve only a short operating life. This is particularly evident in measurement tasks in flue gas cleaning within waste incineration plants. Longer service life due to increased corrosion resistance UWT has further developed the RFnivo® 3100 capacitive level limit switch for this type of measurement task in the dust extraction of flue gases so that it meets and withstands the demanding conditions. All process-contacting parts of the sensor have been designed to be completely

14.01.2021 | 1580x | Product description | |

Non-contact radar level measurement with NivoRadar® NR 3000

A leading supplier of building materials in South Africa was looking after a reliable continuous level measurement solution for his process hopper The application revolved along a train tippler that tips the contents of the train truck with coal into the hopper below which is then conveyed to the site. The measurement units have to meet the highly accurate demands and cope in the challenging environment. The mining sector in South Africa was once the primary driving force behind the history and development of Africa’s most advanced and richest economy. South African mining companies are key players in global industry and the country is the third largest coal exporter in the world. The plant operator has been producing cement, aggregates, lime, ready mix and fly ash since 1892 and now operates with 11 factories in South Africa, Botswana, DRC, Ethiopia, Rwanda and Zimbabwe. With regard to the modernization of the facilities close to Cape town he was looking after innovative continuous level measurement equipment. Due to the nature of the application, the electromechanical lot system, which is very popular

10.12.2020 | 1813x | Press release | |

Capacitance level measurement with Capanivo in tomato paste production

Precise media detection with two wire electronics and “Tip sensitivity” Tomatoes Capacitance level measurement in tomato paste production Measuring sensors working with the capacitive principle are the all-rounders among limit switches because they have the highest application performance in the basic version. They can be found in overfill protection as well as demand and empty indicators in process or storage vessels as well as in leakage monitoring and interface detection and can be used in all tank types and shapes, regardless of whether the vessels are metallic or non-metallic. Due to their high sensitivity, their compactness and the variety of booms, they are particularly suitable for the different process requirements of the nutrition industry. A well-known manufacturer of different foods within the Latin American markets implemented the capacitance level indicator Capanivo® from UWT GmbH for his tomato paste container at the Lima location. For full detection the CN 7000 series was applied, which has process connection made of stainless

01.12.2020 | 2349x | Product description | |

Rotary paddle Rotonivo® the reliable solution for level control

Simple and reliable measurement technology by UWT A level limit sensor has to cope with low bulk density, bridging, caking, abrasiveness, corrosion, leverage forces, high and low process temperatures, electrostatic charging and so on. Rotating level limit switches of UWT have been designed to meet these challenges of different industry sectors and cover various changing approaches, also within extraordinary applications. The rotating paddle switch can be used as full, demand or empty detectors in silos or containers. The trusted, multifunctional and maintenance free unit for level monitoring of bulk goods is versatile and has a modular design. With its simple electromechanical measuring principle it can also be adapted for extreme process conditions. A motor driven shaft causes the vane to rotate. Once the material level reaches the vane, thereby preventing further rotation, this creates a torque, which is converted via a switch to an electric signal. When the vane is free again of the material, the output signal

17.11.2020 | 1791x | Product news | |

UWT - Solution with Capanivo® CN 7 in xylene through a glass pane

Secure full detection of xylene by side mounting of the level switch Capanivo® with 1-inch stainless steel process connection in a 3" MS pipe. Level indicators working with the capacitive measurement principle can be used in all types and shapes of tanks, regardless of whether these are metallic or non-metallic. Due to their high sensitivity, their compactness and the range of probes, they are suitable for a wide variety of industrial process requirements. In order to coordinate a constant flow of material, timed to match the manufacturing process, the plant manager of a huge paints corporation was looking for a robust and compact level monitoring system for xylene tanks. Due a special installation situation a creative solution was required. PPS probe with 1-inch process connection Chemical resistance & compact design An Indian multinational paint company headquartered in Mumbai was looking after a solution to detect the level of xylene within several process tanks. Xylene is a common component of ink and solvent of paints and varnishes and is used by conservators of art objects. The company is considered

16.11.2020 | 1732x | Product news | |

Safe level measurement in ethanol tanks with TDR NivoGuide NG 8000

For the storage processes of ethanol of a Swedish producer the guided wave radar for continuous level determination was implemented within several tanks. In addition, TDR sensors meet the highest safety standards, which makes them the technology of choice especially in the oil, gas and chemical sectors. With these capabilities, TDR sensors make a noticeable contribution to increasing the productivity of the plant. Robust sensor design that can be used in a variety of ways Radar technology has gained more and more importance over the past decades and has been continuously developed. The area of application now extends from simple installations to complex process vessels with a wide variety of challenges. In addition to free-radiating radar sensors, the radar category also includes those based on guided microwave technology, which are often referred to as TDR (Time Domain Reflectometry) or GWR (Guided Wave Radar). Above all, the versatility and insensitivity to changing process conditions make TDR sensors a popular all-rounder. In the course of modernizing its plants, an ethanol producer in Sweden was looking for a smart

27.10.2020 | 2329x | Product news |

Interface Measurement in liquid layers

UWT offers you the right solution for your interface measurement Continuous measurement There are applications not only in the chemical, petrochemical or oil & gas industries but also in other industries, such as Oil & fat separators where a separating layer between two liquids or a liquid and foam is to be measured. The particular challenge for the measurement technology are mainly deposits, adhesions, chemicals and any emulsion layers that may occur. With the NivoCapa® 8000 and NivoGuide® 8000 series, UWT offers two reliable sensor families that meet the most diverse media to be measured, requirements and installation positions. Point Level Measurement The capacitive measuring method is ideally suited to precisely record or measure the transition between two liquids or a liquid and foam. Sensors for interface measurement are designed to have a high sensitivity, a high chemical resistance and a robust design with regard to mechanical stress and deposits or adhesions. With the Capanivo® 7000 and Capanivo® 8000 series and the

20.10.2020 | 2367x | Product news |

Precise interface measurement of different solids in liquids

Project planning options for interface detection with NivoBob® or Vibranivo® from UWT There are several industries where sludge levels or solids in liquids need to be measured. For example, in sediment containers or basins, filters or lamella separators in the metal industry, chemical plants, lime or gravel works and the waste water industry. The measuring accuracy and durability of the sensor technology is important. Dirt, chemicals and gases often affect the sensors and require special resistance. The NivoBob® series NB 3300/3400 meet the requirements of many interface measurements and are very reliable due to the simple measuring principle. For level evaluation an analogue signal 4-20mA and a Modbus RTU/Profibus DP interface are available. Vibrating forks of the Vibranivo® series VN 1000 or VN 5000 can be used to measure the level of sludge and solids in liquids. The parts in contact with the medium are made of resistant stainless steel. With the versions VN 1030 and VN 5030 even depths of approx. 4 m when installed from above in a tank or basin.

19.10.2020 | 2268x | Product description | |

Multitalent tdr in solids & liquids

Solutions for tricky level measurement challenges What is radar? Radar is the abbreviation for "radio detection and ranging" which means "radio-based location and distance measurement". This technology is based on electromagnetic waves. A radar device emits a concentrated electromagnetic wave, which is reflected by objects as an echo and then evaluated by the device according to various criteria. Depending on the application, the following information can be obtained from the reflected waves: -the angle or the direction to the object -the speed of an object (Doppler effect) -the contours of an object -the distance to the object The latter point means that radar technology is also used for determining fill levels. This has become increasingly important in recent decades and has been continuously developed. The areas of application now extend from simple storage tank applications to complex process containers with a wide variety of challenges.

02.10.2020 | 2767x | White paper |

Capacitance empty detection with Capanivo® from UWT in sulfuric acid

PPSChemical resistance & compact design with the probe with 1-inch process connection Level indicators working with the capacitive measurement principle can be used in all types and shapes of tanks, regardless of whether these are metallic or non-metallic. Due to their high sensitivity, their compactness and the range of probes, they are suitable for a wide variety of industrial process requirements. A well-known manufacturer of aluminum sulfate in Peru was looking for a compact level measurement for its raw material tanks with 98% sulfuric acid. Due to the strong corrosion caused by the acidic material, the decision was made to implement the robust capacity indicator Capanivo® CN 7000 from UWT GmbH. PPS probe with 1-inch process connection Chemical resistance & compact design Sulfuric acid is extracted from sulfur in a number of ways and is one of the most dangerous acids known in the world. The colorless and odorless chemical is viscous, water-soluble, hygroscopic and hardly corrosive. Due to its properties, sulfuric acid is used in a large number

16.09.2020 | 2615x | Product description | |

Your answer to solving challenging level measurement applications

More information about our capacitive Solution Capanivo® CN 7 The video shows solutions for difficult challenges. Capanivo® level switches can be used in many bulk solids and liquids as full, demand or empty indicators. The robust probe made of glass fibre reinforced plastic PPS is even suitable for food and resistant to many aggressive media. The Capanivo® can be used in storage and process vessels or in pipes as level switch and backwater detector.

18.08.2020 | 2191x | Press release | |

UWT NivoGuide® Solutions for tricky level measurement applications

Solutions for tricky level measurement challenges Looking for precise and safe continuous level measurement even when dealing with difficult process conditions such as a dusty atmosphere, material with a low DK-value, very tall silos or particularly high loads on the probe? Are you faced with strong surface waves, fixings inside the tank or small tanks you wish to fill right to the top? Are you handling material in a high temperature, high pressure or steam environment? Are you confronted with challenges such as Interface Measurement?

21.07.2020 | 2359x | Product news |

UWT managing director expands management team

A dynamic trio for a stable future In recent years, UWT GmbH has built up many new customer relationships in a wide variety of countries and regions, opened up new sales channels and gained valuable, competent employees for the company. In order to meet the associated growing challenges with a stable, future-oriented organization, Uwe Niekrawietz decided to form a trio in UWTs Board of Directors. In addition to Managing Partner Uwe Niekrawietz, there are two further Managing Directors since June: Former technical manager Andreas Haug has been appointed as Managing Director for Operations and Technology. Markus Schalk, who had previously been responsible for international sales at UWT, takes over the responsibility on the commercial side with all assigned areas and departments as Managing Director. A lot has going on with the 40th anniversary of UWT GmbH. The company`s course is focused on expansion. Uwe Niekrawietz knows the UWT well and has grown with it since 1997. Since January 1999 as managing director

14.07.2020 | 2326x | Press release | |

Guided wave radar technology for continuous level measurement

UWT solution in maceration process Guided wave radar technology for continuous level measurement in maceration processes For the cellulose production of a wood manufacturing plant in South America, the guided wave radar was implemented in several water tank constructions within the maceration processes. The modern, high-quality TDR technology ensures a continuous production process of the plant. Uninfluenced by changing process conditions, TDR sensors detect the level reliably and precisely and thus offer optimum support for a smooth process flow. +/-2 mm measuring accuracy & steam compensation A wood manufacturer who has been operating in the forestry, cellulose and paper industry for 100 years was looking for an innovative and durable solution to modernize the level measurement within his plant processes as part of a stronger strategic focus on sustainability. The company is active in Chile, Argentina, Brazil, Peru, Colombia, Mexico, Ecuador and Uruguay and is considered the fifth largest pulp and

07.07.2020 | 2102x | Press release | |

Capacitance point level detection in liquid naphthalene

UWT application of the month Full detection with high process compatibility in chemical plant operation The measurement technology a chemical plant was looking for in his liquid naphthalene tanks has to deal with different temperatures, varying DK values and viscosity. In order to meet these conditions in practice quickly and reliably with a clever solution, the capacitive rod probes of the RFnivo® series from UWT were implemented. Changing process temperatures and caking on the sensor boom In the liquid state, naphthalene is an aggressive substance that quickly corrodes common materials. If it becomes firmer as it cools down, it tends to become heavily attached. For the individual tanks with liquid naphthalene, the system operator therefore needed reliable and robust level monitoring, which can be flexibly adapted to the fluctuating ambient conditions. The chemical manufacturer has several storage tanks that are electrically heated to maintain the melting point of the naphthalene. There is

26.05.2020 | 2244x | Press release | |

Precise media detection for adhering raw materials

Capacitance level measurement in blender for animal feed production The animal feed manufacturer Sano – Moderne Tierernährung GmbH has been installed the integral version of the capacitance Capanivo® CN 7100 limit sensor for his blending processes. With its reliable media detection and short reaction time, the sensor helps to ensure the correct mixing proportion of the individual components, the homogeneous distribution and also the lasting quality of the end product. About 50-100 kg of liquid components of the most different liquid media are added to about 3 tons of solid content. These are injected into the mixing container within one minute by a special injection device. For this purpose, the various liquids are injected from storage tanks or mobile containers (GRP), with a pressure of up to 5 bar, into the mixing container via a distributor attached to the mixer. Secure media detection and short response time The Capanivo® level switch installed in the distributor ensures both that the liquid intended by the control system

06.04.2020 | 2439x | Press release | |

Innovative solutions for cooling tanks of the power industry

Contact-free radar sensor for content level measurement detection in seawater tanks In Malaysia, a plant operator in the power generation field was looking for a smart solution for continuous level monitoring of its seawater tanks. To meet the challenges of space constraints and the salty atmosphere within the containers with robust accurate content detection, the NivoRadar® NR 3000 contact-free radar sensor with robust stainless steel housing was used. The radar sensor works with a high-frequency 78 GHz signal, which is emitted with a very narrow beam of only 4°, reflected by the sea water and received again by the sensor. The frequency difference, which is directly proportional to the distance, is then further processed and output as a fill level signal. In order to properly position the radar within the seawater tanks so as to ensure accurate level monitoring, a special housing construction was designed in which the device was installed. The NivoRadar® can easily be combined with the Nivotec® visualization system and offers a good combination

23.03.2020 | 2274x | Press release | |

Certified level sensors for applications in desert areas

Solutions for plants around the Persian Gulf Along with several distributors Aiman Gayed, UWT Area Sales Manager for the Middle East and North Africa region, visited various plant operators around the Persian Gulf, who needed different level measurement technology to optimize their manufacturing processes. In particular, continuous level and point level measurement for storage and conveying processes as well as dosing, mixing, filling and drying was of great interest. The product portfolio with its many configuration options for different process conditions was presented for different industries. Among them the classic device Rotonivo®, a rotary paddle switch that has proven itself many times in difficult media detection and is also certified according to SIL 2 in addition to the current international approvals. In most of the regions where the measurement instrumentation was or will be used, there are desert areas and there is a predominantly dry, humid climate with high temperatures and a dusty environment.

23.03.2020 | 2462x | Press release | |

Innovative. Precise. For challenging conditions and material

New NivoRadar® 3000 The robust stainless steel construction makes the continuous non-contact level measurement NivoRadar® NR 3000 extremely suitable for all kinds of industrial applications. The unit operates at a high frequency of 78 GHz. This delivers a very small beam angle of 4° which eliminates any signal interference at the flange but allows for optimum reflection of the bulk solids material. You can measure distances up to 100 meters and the sensor can be used especially in very fine solids due to the high sensitivity. The NivoRadar® offers a flat flange version and also an aiming flange version. Using the adjustable aiming flange, the radar is perfectly aligned since the probe can be fixed to the desired point. In other words, the angle of the beam can be set to a specific point; for example, at the outlet of the silo. The lens antenna is highly resistant to material deposits and offers a self-clean function for extremely sticky solids using an air flush connection.

20.12.2016 | 5042x | Product news |

Product highlight 2016: the new vibrating rod probe Mononivo

Many applications – One solution It has often been the case that a single rod probe, using the vibrating principle and having universal design capabilities, is required. This measurement principle has become well-established on the international market. Due to its high compatibility (even with the standard version), it is much favored by plant operators. UWT has responded to the wishes of their customers with a new product series that uses this vibration measurement principle in the form of a single rod probe called Mononivo® MN 4000. The new vibrating rod Mononivo® MN 4000 is now available. The Mononivo® MN 4000 vibrating rod • is a point level detector • that can be used in silos and tanks • as a full, demand or empty detector Electronically stimulated piezos cause the single rod probe to vibrate. When the material covers the sensor, this causes the vibration to stop and a voltage change is caused within the piezo elements. This is electronically registered and causes the output

20.12.2016 | 4530x | Product news |

Efficient silo management for smooth process flow

The electromechanical Lot system Nivobob® 4000 is now equipped with a Modbus function UWT GmbH has developed an economical and practical solution in terms of centralized content level monitoring; especially suited for the storage processes within industrial plants. First the maintenance-free electromechanical lot system Nivobob® is mounted on each silo within the plant for continuous level monitoring. The plumb bob systems of the economical Nivobob® 4000 series are now shipped with a Modbus interface as standard which allows for quick and easy connection of the units to the visualization system. The operation of the installed sensor devices is made absolutely transparent, as the operating status and all diagnostic parameters, taken during the communication of the units, are recorded in the Modbus register. Parameters such as content level, operating time, pending replacement intervals, sensor status and much more are available to the operator. For level control, diagnostics etc. the license-free visualization software Nivotec® is used: The information

20.12.2016 | 4564x | Product news |

1 million times successfully solved level detection

With the right attitude and a great team, anything is possible The UWT GmbH has become one of the world leading manufacturers of measurement technology for the detection of content and level limit in any kind of bulk materials and solids. Different measurement methods in storage silos, containers or tanks are installed to monitor their content and control it. Applications can be found in food, plastics, wood, rubber, environmental plants and power stations as well as the building materials and chemical industry. Headquarters, development and production facilities are located in Betzigau. Besides UWT is represented in more than 50 countries worldwide and has own sales offices in the US, UK, in China and India. End of August 2015, it happened: the installation of an RF detector for a considerable cement and lime producer, the 1,000,000th application has been successfully implemented. The RF sensor is the new capacitive level switch of UWT. For the anniversary application the single rod probe was installed as tailback detector

22.09.2015 | 4721x | Press release |

COMPANY PAGE

Our portfolio includes sensors for liquids:

Sensors for bulk solids:

Articles

Job openings

Posts
